Dual Sensor Gimbal Camera For Long Range Surveillance And Inspection
TS01BT is around 1kilogram dual-sensor UAV gimbal camera , support 2 channels RS422 and 1 channel HDSDI video output, buit-in 25mm 640x512 12μm IR thermal camera and 905nm 1000m laser rangefinder, average power consumption is 15W, It with 3-axis high-precision gimbal which has advantages of better aluminum alloy housing , with good anti-interference and better heat dissipation. It widely used in UAV,fixed wing,helicopter industries of long range inspection, surveillance, search and rescue and other industrial applications.
Functions
1. Provide the infrared video and image for detection area
2. High precision visual axis stabilization function
3. With the capability of detection and recognition for ground target
4. Support search, tracking, lock, guiding, etc working ways
5. With character overlay, custom and display functions;
6. With self - check and fault diagnosis function
7. support target postion and laser ranging
8. Self-inspection and fault diagnosis
Specifications
| IR sensor |
IR Type |
LWIR(un-cooled) |
| Wavelength |
8～14μm |
| Resolution |
640x512 |
| Pixel |
12um |
| NETD |
50mk |
| Focus length |
25mm/F1.0 |
| FOV |
17.4º×14º |
| Distance |
PEOPLE:Detection 0.7km; Recognition 0.22km
VEHICLE:Detection 4.2km; Recognition 1km |
| Laser rangefinder |
Wavelength |
905nm |
| Performance |
3m~1km |
| Ranging distance |
3~1000m |
| Ranging accuracy |
±3 |
| Servo System |
Rotating limits |
360º continuous Pan, Pitch: -110° ~+10 º |
| Angular accuracy: |
≤2mrad |
| Stablization accuracy |
≤100μrad(1σ)(2°/Hz,1°/Hz Swing) |
| Max.angular speed |
≥50°/s |
| Max. angular acceleration: |
≥90°/S |
| Tracking Functions |
Motion speed: |
30pixel/frame |
| Target imaging contrast: |
8% |
| Target imaging pixel(Mini) |
4x3 pixels |
| Support |
Anti -occlusion without loss of function |
| Interface |
Communication
interface |
RS422 x2(TTL optional) |
| Video output |
HD-SDI x1 |
Mechanical Drawing
